Titanium Grade 2 is unalloyed Titanium with standard Oxygen. It is called the “workhorse” of the commercially pure titanium industry, thanks to its varied usability and wide availability. It possesses good weldability, strength, ductility and formability.

Titanium Grade 2 Chemical Composition, %:

C	Fe	H	N	O	Ti
0.1 Max	0.3 Max	0.015 Max	0.03 Max	0.25 Max	99.2

Titanium Grade 2 ASTM Specification:

Pipe Smls	Pipe Welded	Tube Smls	Tube Welded	Sheet / Plate	Rod and Bar
B861	B862	B338	B338	B265	B348

Mechanical Properties of Titanium Grade 2:

Ultimate Tensile Strength	344 MPa or 49900 psi
Yield	(0.2 % offset) 275 - 410 MPa Or 39900 - 59500 psi
Elongation	20 %

Titanium Grade 5 alloy is the most widely used titanium grade. It is a two phase α+βtitanium alloy, with aluminum as the alpha stabilizer and vanadium as the beta stabilizer. This high-strength alloy can be used at cryogenic temperatures to about 800°F (427°C). Ti-6Al-4V, Grade 5 alloy is used in the annealed condition and in the solution treated and aged condition. This alloy is produced by primarymelting using vacuum arc (VAR), electron beam (EB), or plasma arc hearthmelting (PAM). Remelting is achieved by one or two vacuum arc steps.

Titanium Grade 5 Chemical Composition, %:

Al	Fe	O	Ti	V
6	0.25 Max	0.2 Max	90	4

Titanium Grade 5 ASTM Specification:

Specification Minima

Sheet / Plate	Rod and Bar
B265	B348

Mechanical Properties of Titanium Grade 5:

Ultimate Tensile Strength	1170 MPa or 177000 psi
Yield	(0.2 % offset) 1100 MPa Or 160000 psi
Elongation	10 %

Titanium Grade 7 is an unalloyed titanium grade with standard oxygen content and addition of palladium. It is used mildly reducing or fluctuating conditions. At room temperature it is an alpha alloy. It transforms to beta phase at 913°C, and the alpha phase returns on cooling 890°C.

Titanium Grade 7 Chemical Composition, %:

C	N	Ti	Fe	O	H	Pd
0.08 max	0.03 max	Balance	0.30 max	0.25 max	0.015 max	0.12-0.25

Titanium Grade 7 ASTM Specification:

Pipe Smls	Pipe Welded	Tube Smls	Tube Welded	Sheet / Plate	Rod and Bar	Forgings
B337	B337	B338	B338	B265	B348	B381

Mechanical Properties of Titanium Grade 7:

Typical Mechanical Properties, Annealed:

Tensile Strength	345 MPa or 50 Ksi min
Yield	(0.2 % offset) 275-450 MPa Or 40-65 Ksi
Elongation in 2”	20 %
